| Place of Origin | CHIINA |
| Brand Name | SEW |
| Certification | CE/3C |
| Model Number | R37 DRN63M4 |
The Gear Motor Reducer is a highly efficient industrial reducer that is designed for use in various applications. With its compact structure and high efficiency, it is the perfect solution for any industrial setting.
The Gear Motor Reducer is designed to be mounted with M1-M6 mounting options, allowing for easy installation and versatility in use.
With a power output of 0.18 KW, the Gear Motor Reducer is capable of handling heavy-duty tasks with ease. This makes it the ideal choice for industries that require a strong and reliable power source.
The Gear Motor Reducer has a speed of 62 revolutions per minute, providing a smooth and consistent rotation for any application. This speed is suitable for a wide range of industrial processes and ensures optimal performance.
The Gear Motor Reducer has a wide temperature range of -20℃ to +40℃, making it suitable for use in various environments. It can withstand extreme temperatures, ensuring consistent performance and durability.
The Gear Motor Reducer is a helical gear speed reducer, which is known for its high efficiency and smooth operation. This type of motor is widely used in industrial settings due to its reliable and durable performance.
The Gear Motor Reducer is the perfect combination of power, speed, and durability. Its compact structure and high efficiency make it an essential component for any industrial process, ensuring smooth and reliable operation.
The RX series offers highly efficient helical gear units in 6 sizes. These units have a high output speed of up to 830 Nm and gear unit ratios of up to i = 8.65. They are available in foot or flange-mounted design for easy installation.
The R series offers 15 sizes with an optimum ratio between performance and space requirements. These gear units have finely stepped ratios up to i = 289.74, or i = 27,001 for double gear units. They are also available in foot or flange-mounted design, and can be purchased with reduced backlash for improved efficiency.
The R series boasts a gear transmission efficiency of up to 98%, low vibration, and low noise for a smooth and quiet operation.
Solid shaft, flange, or footing mounting options are available, making it versatile and suitable as the input stage part of a multi-stage reduction box. It has a wide output speed range of 0.05rpm to 1829rpm and a torque range of 50Nm to 18,000Nm, with a power range of 0.09KW to 160KW.
The R series is available in sizes R37, R47, R57, R67, R77, R87, R97, R107, R137, R147, and R167. It also has variations such as RS (solid shaft) and RF (footing mounting) in the same sizes.
The RX series is available in sizes RX37, RX47, RX57, RX67, RX77, RX87, RX97, and RX107. For added flexibility, variations such as RXF (flange-mounted) are also available in the same sizes.
The RX and R series gear units are reliable, efficient, and versatile options for any industry with their various sizes, mounting options, and high-performance capabilities.
| Product Attribute | Value |
|---|---|
| Input Speed | 1375 Rpm |
| Color | GRAY BLUE |
| Output Speed | 62 Rpm |
| Power | 0.18 KW |
| Ratio | 22.27 |
| Mounting | M1-M6 |
| Speed | 62 r/min |
| Temperature Range | -20℃~+40℃ |
| Type | Helical Gear Motor |
| Efficiency | ≥95% |
| Product Attribute | Value |
|---|---|
| Gear Speed Reducer | Yes |
| Gear Reducer Gearbox | Yes |
| Custom Gear Motor | Yes |
| Input Speed | 1375 Rpm |
| Output Speed | 62 Rpm |
| Power | 0.18 KW |
| Ratio | 22.27 |
| Mounting | M1-M6 |
| Speed | 62 r/min |
| Temperature Range | -20℃~+40℃ |
| Type | Helical Gear Motor |
| Efficiency | ≥95% |
Gear Motor Reducer - SEW R37 DRN63M4 is a high-quality, versatile and durable helical gear speed reducer, designed for various industrial applications. With its advanced technology, reliable performance and exceptional quality, it has become a popular choice among industries worldwide.
SEW R37 DRN63M4 is a gear motor reducer designed and manufactured by SEW, a renowned brand in the industry. It is a helical gear speed reducer, which means it is designed to reduce the rotational speed of a motor while increasing its torque. This makes it suitable for a wide range of industrial applications, such as conveyor systems, mixers, agitators, and more.
The SEW R37 DRN63M4 is built with high-quality materials and advanced technology, ensuring its durability and reliability even in the most demanding conditions. It also comes in a stylish GRAY BLUE color, making it not only functional but also aesthetically pleasing.
The SEW R37 DRN63M4 is suitable for a wide range of industrial applications, including:
| Model Number | Ratio | Speed | Color | Temperature Range |
|---|---|---|---|---|
| R37 DRN63M4 | 22.27 | 62r/min | GRAY BLUE | -20℃~+40℃ |
With its high-quality construction, advanced technology, and exceptional performance, Gear Motor Reducer - SEW R37 DRN63M4 is the perfect solution for your industrial needs. Contact us today to discuss your requirements and get a quote.
